Application Scope:
Suitable for cold shearing of diverse metal profiles (round bars, square bars, channels, angles, I-beams), plates, and scrap structures, transforming materials into charge-ready fragments for efficient storage/transportation. Serves scrap recycling, smelting industries, and construction machinery sectors.
Technical parameters：
| Model | Shear Force（TON） | Throughput（T/H） | Blade Length（MM） | Throat Opening（MM） | Cycles/Min | Material Dimensions（MM） | Total Installed Power（KW） | Operation Modes |
| Q43E-63 | 63 | 16 | 600 | 280 | 9-16 | 30*30 / Round Bar φ35 | 7.5 | Single-Cycle Mode/Continuous-Cycle Mode |
| QGL4-100 | 100 | 16 | 600 | 280 | 9-16 | 40*40 / Round Barφ45 | 11 | |
| Q43E-120 | 120 | 20 | 600 | 280 | 9-16 | 45*45 / Round Barφ50 | 15 | |
| Q43E-160 | 160 | 25 | 700 | 320 | 9-16 | 55*55 / Round Barφ63 | 18.5 | |
| Q43E-200 | 200 | 25 | 800 | 380 | 9-16 | 65*65 / Round Barφ75 | 22 | |
| Q43E-250 | 250 | 26 | 800 | 480 | 9-16 | 70*70 / Round Barφ80 | 30 | |
| Q43E-315 | 315 | 42 | 900、1200 | 520 | 8-16 | 80*80 / Round Barφ90 | 37 | |
| Q43E-400 | 400 | 42 | 1500 | 700 | 8-16 | 90*90 / Round Barφ100 | 44 | |
| Q43E-500 | 500 | 42 | 1600 | 900 | 8-16 | 100*100 / Round Barφ110 | 44 |
